Search found 72 matches

by Ola H.
Sat Jan 18, 2020 3:58 pm
Forum: Equipment
Topic: Rules of Thumb for waveboard design
Replies: 12
Views: 353

Re: Rules of Thumb for waveboard design

On mast foot: I see this as a very important design and tuning dimension. Not so much or tuning the feel or adjusting to sail sizes as one classically thought. Rather I see it as a way to tune the responsiveness of the board and actually also the sail. This goes by the assumption, that the sailor wi...
by Ola H.
Sat Jan 18, 2020 1:50 pm
Forum: Equipment
Topic: Rules of Thumb for waveboard design
Replies: 12
Views: 353

Re: Rules of Thumb for waveboard design

Excellent post from Ola (https://sailboardsforum.com/viewtopic.php?f=3&t=116&start=90) has detailed discussion on board design. Is there a simplified summary of what varying features of design do? I know they are inter-related so a few rules of thumb to start my understanding. In another post Ola s...
by Ola H.
Sat Jan 18, 2020 10:08 am
Forum: Equipment
Topic: Board design by Ola H.
Replies: 110
Views: 6938

Re: Board design by Ola H.

Here’s a question for you ola: with your main team rider/tester Marc Pare gone from the team, will there be a big change in board design do you think? Ie the feedback from alessio will be different as he is a different shape, weight etc and has a different style from Marc, so the boards could turn ...
by Ola H.
Tue Jan 14, 2020 3:50 am
Forum: Equipment
Topic: Board design by Ola H.
Replies: 110
Views: 6938

Re: Board design by Ola H.

TOTD wrote:
Thu Jan 09, 2020 3:57 pm
Ola, you mention your preference,
Is this what is being installed on the Simmers?
Or just your own boards
Or a variable on both
The data on the FLy, Quantum, Cortex and Helix are for the production boards. The two others mentioned are my own protos.
by Ola H.
Thu Jan 09, 2020 1:15 pm
Forum: Equipment
Topic: Board design by Ola H.
Replies: 110
Views: 6938

Re: Board design by Ola H.

Sounds like more toe than you used to? I run 4.8° at the base now but that goes back to 0.4° on a 12.5cm fin. So average 2.6°, less than yours. But the asymmetry flows out towards the tip. I recently measured a fairly new Starboard and it had 1.5°. I have been using the same for at least three or f...
by Ola H.
Sun Jan 05, 2020 8:26 pm
Forum: Equipment
Topic: Board design by Ola H.
Replies: 110
Views: 6938

Re: Board design by Ola H.

I run between 1.3 and 1.8 degrees of toe in the fronts and from 0-0.8 degrees in the back (in some extreme case 1.3 in the back). The Cortex comes in at 1.8/0.7 The Quantum at 1.5/0 The Fly at 1.8/0.5 The Helix is 1.3 (no rear quad boxes) The limelight, one of my personal boards, is 1.8/0.7. The Tor...
by Ola H.
Wed Jan 01, 2020 8:26 pm
Forum: Equipment
Topic: Board design by Ola H.
Replies: 110
Views: 6938

Re: Board design by Ola H.

Some chance if I can have my ways, but then as a later release. We need more testing time on more sizes and also need to think about how much market appeal such a board would have. That equation is in itself quite dependent on another new boards that will most surely make production and kind of sit ...
by Ola H.
Tue Dec 31, 2019 2:44 pm
Forum: Equipment
Topic: Board design by Ola H.
Replies: 110
Views: 6938

Re: Board design by Ola H.

Happy new year everyone. I'm signing off the year 2019 with two new board models that have serving in the Simmer range for a long time, the Freemove and the Helix. Now they will both see some updates. I combined both models in all sizes in one pic here. http://ncm.gu.se/media/users/ola/Public/Boards...
by Ola H.
Thu Dec 26, 2019 7:40 am
Forum: Equipment
Topic: New Bruch Board
Replies: 12
Views: 798

Re: New Bruch Board

V= the central spine of the board is lower than the rails Flat v= each panel of the v is flat (rather than having a concave in it) Double concave=the panels on each side of the central spine of the board has a concave, in total forming two parallel concaves. Single concave= the rails are lower than...
by Ola H.
Wed Dec 25, 2019 9:05 am
Forum: Equipment
Topic: New Bruch Board
Replies: 12
Views: 798

Re: New Bruch Board

Sorry Ola, that is even more confusing, without double concave on a flat Vee. I thought F1 was technical . So a genuine flat vee is standing proud of a flat bottom. Do you measure the rocker on the vee or on the flat? V= the central spine of the board is lower than the rails Flat v= each panel of t...
